Teeter FreeStep LT3 - STEP 2: Assemble Pedals

6
Attach Rear Stabilizer Cover Set
Figure 3: Locate the Rear Stabilizer Cover
Set, noting the Right and Left markings,
and the Step 1b Hardware Kit.
Attach the Right Rear Stabilizer Cover by
loosely tightening the 1 x Machine Screw.
Figure 3a: Attach the Left Rear Stabilizer
Cover to the Right by joining the alignment
pegs and pushing together for a snug fit.
Insert 1 x Machine Screw to secure the Left
Rear Stabilizer, then finish tightening both
Machine Screws with the Screwdriver.
Complete this first before Part 2.
Figure 3
Figure 3a
61
Machine Screw
Part 1
Part 2
Step 1b Hardware
Figure 4: Locate the Seat Post and raise it to
the highest position by loosening the Height
Adjustment Knob and pulling up on the
Seat Handle.
Pull Handle
Lift and Flip
CAUTION
!
Use caution to avoid tipping and when
lifting heavy objects.
FIGURE 4
STEP 2
ASSEMBLE PEDALS
Figure 5-6: To have better access while
installing the pedals, position the FreeStep
to rest on its back side by lifting up on the
Front Crossbar and rotating on the Rear
Stabilizer until the Seat Post is resting on
the ground.
Figure 4
Figure 5 Figure 6
Part 1
Part 2
