STEP 1
Attach Support Beam to Table Bed
• Locate the Table Bed Assembly Hardware Kit (HK1010)
• Place the FlexTechnology™ Table Bed face down on the floor.
• Push down on the Support Beam so that the two holes align evenly
with the holes at the base of the Upper Support Arms (Figure 1).
• Insert the two bolts into the open holes (Figure 2).
• Hand tighten each bolt with a washer and nut (Figure 3). Use the
6 mm Allen Wrench to steady each bolt and tighten the nuts
using the 10/13 mm Open-Ended Wrench provided.
6
1 - Support Beam 2 - Upper Support Arms 3 - Rubber Spacers
FIGURE 1
FIGURE 2
FIGURE 3
2
1
3
