● Insert the displacer into the new filter
cartridge in such a way that the displacer’s
screw passes through the opening in the
base of the filter cartridge.
Check whether the seal is in
contact at the thread of the displacer and
that it is undamaged. Otherwise, it is
necessary to use a replacement seal (see
spare parts list).
● Screw the displacer tight with the cylindrical
nut.
When you do this, the side of
the large chamfer (A) of the cylindrical
nut must face outwards.
● Insert the cartridge holder without a new filter
cartridge in one of the cartridge guides.
However, only do this for one side. The other
side of the cartridge holder should continue
to hang freely.
BA_FilterCube_4_IFA_20230808_EN
