Teka LP8 850 - Page 12

Service Manual
Dishwasher LP8 850
Service Manual: MS-DW-0071-00-0913 - 11 -
There is a flat connector for the
display panel (CN4).
If you have to check the outputs
of the PCB, always connect one
probe of the multimeter to ACN.
In order to check the inputs of the PCB use the terminal of the device to
check.
EV3
Half load Valve
output
ISS
Salt Detector
input
ISB
Rinse detector
input
IAQS
Overflow switch
input
FM
Flow meter
input
