Teka LP8 850 - Washing Pump

Service Manual
Dishwasher LP8 850
Service Manual: MS-DW-0071-00-0913 - 7 -
Washing Pump
M – Main Coil
A – Auxiliary Coil
It is an asynchronous motor with capacitor. The stator is made with steel
stack and 2 coils, main and auxiliary.
If there is a problem with the washing pump the error shown on the
display will be E3.
If the rotor is blocked the thermal protection will switch off the washing
pump, if the capacitor is failing or the coil is broken, the display will also
show E3.
Nominal voltage (V AC)
220-240
Frequency (Hz)
50/60
Resistance (Ω)
Main 120,10
± 7%
Auxiliary
107,7 ± 7%
Flow rate (L/min.)
≥ 50
Lock Rotor current (A) (230VAC)
0,5 ± 10%
Operating current (A) (230VAC)
0,24 ± 10%
Capacitor µF/ V
3/425
