Drain Pump
Following the line of the new design, the drain pump is directly mounted
on water sump assy.
It is fixed with a bayonet system, quarter turning.
The motor of the pump is a permanent magnet synchronous type. This
permanent magnet has a very low inertia while the stator has the coil. It is
commanded by the PCB.
The drain pump failure is reported on the display with a message showing
E1, E2 or E4, depending on the origin of the problem.
Nominal voltage (V AC)
220-240
Frequency (Hz)
50/60
Resistance (Ω)
167 ± 10%
Flow rate (L/min.)
≥ 17 L/min. (230
VAC)
