BAS Menu (1 of 2)
Description Range Access
BAS TYPE
Select the communication protocol used with the BAS network.
None = No communication. The control operates in stand-alone.
BACnet-IP = The control communicates to a BACnet-IP BAS system.
BACnet-MSTP = The control communicates to a BACnet-MSTP BAS system.
Modbus = The control communicates to a Modbus BAS system.
Conditions: Always available.
None, BACnet-IP,
BACnet-MSTP,
Modbus
Default = None
Installer
BACnet-IP DEVICE ID
Select the BACnet-IP device identification number. Each device on the BACnet system must
have a unique identification number.
Conditions: Available when BAS Type is set to BACnet-IP.
0 to 4194302
Default = 1
Installer
BACnet-IP PORT
Select the BACnet-IP port number. The default BACnet port is 47808 (0xBAC0 in hexadecimal).
Conditions: Available when BAS Type is set to BACnet-IP.
0 to 65535
Default = 47808
Installer
IP CONFIGURATION
Select if Dynamic Host Configuration Protocol (DHCP) is used to automatically provide an
IP address (Auto) or use a manually set IP address (manual) on the BACnet-IP network.
The Help screen shows the following information:
• IP Configuration
• IP Address
• Subnet Mask
• Gateway IP
• Link Status
• Speed Status
Conditions: Available when BAS Type is set to BACnet-IP.
Manual or Auto
Default = Auto
Installer
IP ADDRESS
Set the IP address on the BACnet-IP network. All BACnet devices must share the same
subnet in order to communicate.
Conditions: Available when 1) BAS Type is set to BACnet-IP, and 2) IP Configuration is set to
Manual.
000.000.000.000
to
255.255.255.254
Default =
192.168.0.200
Installer
IP SUBNET MASK
Set the subnet mask on the BACnet-IP network.
Conditions: Available when 1) BAS Type is set to BACnet-IP, and 2) IP Configuration is set to
Manual.
000.000.000.000
to
255.255.255.254
Default =
255.255.255.0
Installer
IP GATEWAY
Set the Gateway IP address on the BACnet-IP network. All BACnet devices must share the
same subnet in order to communicate.
Conditions: Available when 1) BAS Type is set to BACnet-IP, and 2) IP Configuration is set to
Manual.
000.000.000.000
to
255.255.255.254
Default =
192.168.0.1
Installer
REGISTER FOREIGN DEVICES
Select if a BACnet Broadcast Management Device (BBMD) is on the BACnet network.
Conditions: Available when BAS Type is set to BACnet-IP.
Off or On
Default = Off
Installer
Settings using a number keypad require touching the number field and then pressing the "Clear" button before
entering the number.
