9 of 32 © 2007 D 161 - 08/07
Mode Item Field Range Access Description
2
OFF, -4°F (-20.0°C)
to Hot Tub Maximum
(variable)
USEr
InST
ADV
SET HOT TUB
SECTION B
Display the desired temperature.
3
OFF, -4°F (-20.0°C)
to DHW Maximum
(variable)
USEr
InST
ADV
SET DHW SECTION C
Display the desired temperature.
4
OFF, -4°F (-20.0°C)
to Floor Maximum
(variable)
USEr
InST
ADV
SET FLOOR SECTION D
Display the desired temperature.
1
2
3
4
-31 to 266°F
(-35.0 to 130.0°C)
InST
ADV
SUPPLY TEMP OF tN4 BUS SECTION L
Actual water temperature of the tN4 bus for heating.
Note: This item is only available when the setpoint control
is connected to a tN4 System Control, DIP switch 2 is set
to tN4 System Control, and the Heat Source item in the
ADJUST menu is set to hydronic (HYDr).
VIEW MENU
VIEW Menu (3 of 3)
After the last item, the control returns to the first item in the menu.
To Next Page
