118-0817-007 27
Nova Comet II Wood Lathe Parts List
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
46001
Headstock
1
2
46015
Bed
1
3
C10035
Hex Capscrew
M10X35
4
4
FW10
10mm Flat Washer
4
5
SW10
10mm Spring Washer
4
6
46007
Rubber Feet
4
7
46002
Headstock Guard
1
8
46042
Headstock Guard Pin
1
9
46009
Headstock Guard Lock
1
10
46008/46034
Motor 115V / 230V
1
11
46010
Drive Belt
1
12
46003
Motor Mount Plate
1
13
K0616
Hex Countersunk
Screw M6X16
3
14
46005
Motor Pulley
1
15
G0612
Grub Screw M6X12
3
16
46031
Lock Handle M8X20
2
17
FW8
8mm Flat Washer
2
18
SW8
8mm Spring Washer
2
19
C06015
Hex Cap Screw M6X15
1
20
46006
Spindle
1
21
6005ZZ
Spindle Bearings 6005
2
22
IC47
Headstock Bearing
Retaining Circlip
2
23
46004
Spindle Pulley
1
24
46013
Spindle Index Wheel
1
25
C0620
Hex Cap Screw M6X20
4
26
EC25
Spindle Bearing
Retaining Circlip
1
27
46036
Spindle Hand wheel
(LHB)
1
28
46011
Index Pin
1
29
46012
Index Pin Housing
1
30
TP0412
4x12mm Tension Pin
1
31
46014
Index Pin Spring
1
32
46043
Index Pin Knob
1
