Weight:
77.2lbs (35Kgs) Packaged.
Overall dimensions:
Length: 29.3" approx. (744mm)
Height: 14.5" approx. (370mm)
(Top of headstock from bench)
Swing over bed: 12" (305mm)
Distance Between Centers: 16.5" (420mm)*
(*Can be increased with 24.6”/625mm Optional Accessory
Extension beds)
Headstock:
Spindle Thread: 1"- 8TPI RH.
Headstock Bore: No.2 Morse Taper (2MT)
Through Bore: 3/8" (10mm)
Traverse Hole through Spindle: 3/8"
(10mm)
Tailstock:
Self-Ejecting
Tailstock Bore: 2MT
Quill Travel: 2" (50mm)
Hole Through Tailstock: 3/8" (10mm)
Tool Rest:
Length: 6" (150mm)
Shaft Diameter: 5/8" (15mm)
Motor:
3/4 HP (550W) Average Output
DC (Permanent Magnet) Variable Speed Drive.
Speeds:
Low Speed Pulley: 250 RPM – 680 RPM
(Left pulley step looking at spindle from operator side)
Middle Speed Pulley: 530 RPM – 1420 RPM
High Speed Pulley: 1380 RPM – 4000 RPM
Standard Equipment:
Spindle Hand Wheel
Live Tailstock (Revolving Center) 2MT
Drive (Spur) Center: 2MT
3.15” (80mm) Faceplate
6" (150mm) Tool Rest
Optional Accessories:
Comet II Bed Extension
Nova Versaturn Accessories
Nova G3 Chuck System with reverse direction
lock
