TEKO Broadcast SYNAPSE30 - Section Four; Software Description; Switch on; Parameter Reading Slides

SYNAPSE30 30W FM Exciter User manual
Section Four
SOFTWARE DESCRIPTION
SWITCH ON
Connect the SYNAPSE30 Exciter to a min 50W dummy load and switch ON by pressing
switch located on the rear panel or press the rack switch if Exciter is integrated in a system.
The first slide on display reads
SOFTWARE DESCRIPTION
Software is designed to allow readings / settings of several important parameters of the
Exciter. It is possible to visualize parameters and other stored data without making changes
while Exciter is operating normally. To ensure optimum reading the LCD is placed in the
central section of the front panel, it contains two rows holding sixteen characters and
visualizes the information listed below by simply rotating the encoder.
PARAMETER READING SLIDES
The following slides show the readings of the Main Menu:
“ABOUT” SLIDES
Turn arrows keys to find the ABOUT menu which contains various slides with general
information on Exciter’s Model and Serial number, Address and Web site of Manufacturer /
Distributor etc.etc.
Scrolling down shows Model
