SYNAPSE30 30W FM Exciter User Manual
STEREO OPERATION (Optional)
STEREO OPERATION
Audio frequency response
±0.25 dB da 30 Hz to 15 kHz
Audio input Level
-3 to +9 dBm
Audio input impedance
600 ohm balanced, 10 Kohm unbalanced
Input Connector
Two XLR female L & R ([9]-[10] fig. 2)
Stereo Separation
30÷80 Hz ≥ -50 dB, 80Hz÷15 KHz ≥ -60 dB (Typ. 65 dB).)
Total Harmonic distortion + noise
0.05% @ 400 Hz
Intermodulation Distortion
0.05%, 1 KHz/1.3 KHz, 1:1 ratio
Transient Intermodulation Distortion
0,05%, 2.96 KHz square wave and 14 KHz sine wave.
FM S/N Ratio
-75 dB RMS detector, -71 dB below ±75 KHz deviation, 50 µs
deephasis, weighted.
Stereo Separation
30÷80 Hz ≥ -50 dB, 80Hz÷15 KHz ≥ -60 dB (Typ. 65 dB).
Pilot frequency
19 KHz ± 1 Hz
Phase Pilot
± 2° adjustable
Output Pilot
1 Vpp., BNC female
Audio filter Attenuation
≥ -45 dB @ 19 KHz, > -40 dB 20 KHz to 100 KHz.
Modes
Stereo
OPTIONS
AUXILIARY CONNECTIONS
ELECTRICAL
1. AC Input power
90 - 260 VAC ;50/60 HZ Single phase
2. AC Power consumption
70 VA @ 30W
3. Power Factor
Cos Φ> 0.92
4. Cooling
Forced air
ENVIRONMENTAL
1. Operating temperature
-10° C to + 50° C
2. Guaranteed performance
temperature
0° C to + 40° C
3. Max operating altitude
3,000 mt.
4. Relative humidity range
0 to 90%
PHYSICAL DIMENSION
1. Mounting
Standard 19” chassis 1 U Rack
2. Size
485 mm (W) x 405 mm (D) x 44 mm (H)
3. Weight
~ 4.0 Kg
OPTIONS
CODE
1. RDS/RBDS Coder Programmable with PC
SDZ00100
2. Stereo Coder
SDI03100
3. FCC LPFM Code Station
4. OIRT and JPN Version
