3.2 Dimensions
NTS01 module: Width: 160mm, Depth: 155mm, Height: 40mm , Weight: 0.8Kg.
NTS01E module: as above.
Rack mount: 19” face plate with cut-out for NTS01 display, 1U high.
Each NTS01 unit is normally supplied complete with antenna, antenna mount, antenna cable and
1U 19” rack-mount hardware. Shipping weight of the complete NTS01 kit is 4.8Kg. If the
NTS01E extension unit is included, shipping weight is 5.6Kg, and the unit is shipped already
assembled in the rack mount.
3.3 Identification
Each NTS01 unit is shipped with an identification label on the base. The label provides details of
the particular options fitted to the unit, including the power supply specifications and the unit
serial number.
