a
|
3
es
ob
ta
Basic
Applications
cursors
may
be
used
to
make
voltage
measurements
on
the
ADD
trace
lf
either
CH
1
or
CH
2
Is
displayed
along
with
the
ADD
trace
(and,
of
course,
both
CH
1
and
CH
2
at
the
same
VOLTS/DIV
setting).
If
any
voltage
measurement
function
Is
active,
turning
off
CH
1
and
CH
2
to
display
the
ADD
trace
by
Itself
causes
the
message
“MEASMT
SOURCE:
CH
1
OR
2
ONLY"
to
appear
and
cancels
the
measurement.
If
calling
for
a
voltage
measurement
with
ADD
displayed
and
nelther
CH
1
nor
CH
2
displayed,
the
CH
1
VERTICAL
MODE
Is
turned
on
and
the
measurement
is
initialized
to
the
signal
applied
to
the
CH
1
Input.
Two
common
uses
for
ADD
mode
are:
(1)
providing
a
dc
offset
to
bring
an
ac
signal
riding on
top
of
a
large
de
voltage
within
the
graticule
viewing
area
and
(2)
canceling
out
a
large
line-frequency
signal
component
to
view
some
small
feature
riding on
the
waveform
in
greater
detall
using
common-mode
rejection.
The
following
general
precautions
should
be
observed
when
using
ADD
mode.
a.
Do
not
exceed
the
input-voltage
rating
of
the
oscilloscope
or
probe.
b.
Do
not
apply
signals
that
exceed
the
equivalent
of
about
eight
times
the
VOLTS/DIV
switch
settings,
since
large
voltages
may
distort
the
display.
For
example,
with
a
VOLTS/DIV
setting
of
0.5
V,
the
voltage
applied
to
that
channel
should
not
exceed
4
V,
c.
Use
CH
1
and
CH
2
POSITION
control
settings
which
most
nearly
position
the
signal
on
each
channel
to
mid-screen,
when
viewed
separately.
This
ensures
the
greatest
dynamic
range
for
ADD
mode
signal
displays.
d.
To
have
similar
responses
for
both
channels,
use
the
same
Input
COUPLING
for
both
CH
1
and
CH
2.
The
following
procedure
shows
how
to
eliminate
an
unwanted
ac
Input-
power
frequency
signal
component
from
the
displayed
signal.
a.
Perform
the
“Initial
Setup”
In
“OPERATOR
CHECKS
AND
ADJUST-
MENTS"
Section
4,
and
center
the
baseline
trace
vertically.
b.
Apply
the
signal
of
Interest
containing
the
unwanted
line-frequency
component
to
the
CH
1
Input
connector.
c.
Apply
a
line-frequency
signal
to
the
CH
2
input
connector.
To
maxi-
mize
cancellation,
the
signal
applied
to
the
CH
2
Input
must
be
exactly
In
phase
(or
exactly
180°
out
of
phase)
with
the
frequency
component
to
be
canceled
from
the
CH
1
signal.
2247A
Operators
5-23
