Performance Check Procedure
e. CHECK—the displayed signal amplitude Is 4.2 divisions or more as the
frequency Is Increased to 100 MHz.
f. Repeat the frequency setup and CHECK procedure for VOLTS/DIV
settings of 50 mV and 0.5 V.
g. Move the test signal to the CH 2 Input.
h, Set:
Vertical MODE CH 2 (CH 1 off)
CH 2 VOLTS/DIV 5 mV
|. Repeat the complete Bandwidth check procedure for Channel 2.
17. CH 3 and CH 4 Vertical Bandwidth .
a. Set:
Vertical MODE CH 3 (CH 2 off)
CH 3 and CH 4 VOLTS/DIV O.1V
b. Connect leveled sine-wave generator (SG 503) output to the CH 3
Input via a 50 1 precision BNC coaxlal cable and a 50 2 BNC
termination.
c. Set the generator output for a six-division signal display at 50 kHz.
d.
Set
the
generator
Frequency
Range
and
Frequency
Variable
controls
for a 90 MHz output frequency.
e.
CHECK—that
the
signal
display
amplitude
Is
4.2
divisions
or
more
as
the frequency Is Increased to 100 MHz.
f. Repeat the procedure for 0.5 VOLTS/DIV setting.
g. Move the test signal to the CH 4 input.
h. Set Vertical MODE to CH 4
I. Repeat the procedure for CH 4.
