Tektronix 2247A

Appendix C
MEASUREMENTS
TRACK MEASMT Cursors
TRACK TRIG LVL Cursors
TRACK 7 Cursors
Setup #8: MATCH EDGES
CRT
A INTEN Level
B INTEN Level
READOUT
VERTICAL
MODE
CH 1/CH 2 COUPLING
SCOPE BW
CH 2 INVERT
CH 1 VOLTS/DIV
CH 2 VOLTS/DIV
CH 3/CH 4 VOLTS/DIV
CH 1 /CH 2 VAR
CH 1 POSITION
CH 2 POSITION
CH 3 POSITION
CH 4 POSITION
Disabled
Disabled
Disabled
25% of range
Mid range
Mid range
CH 1 (all others off)
oc
On
Off
50 mV*
10 mv*
.1 VE
Calibrated (UNCAL off)
Ground level at 3rd
graticule line below
center screen
Ground level at Ist
graticule line
below center screen
Ground level at ist
graticule line
above center screen
Ground level at 3rd
graticule line
above center screen
*Multiply scale factor by 10 when 10X probe attached.
