Tektronix 5 Series

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-4 119-8375-XX 1 POWER SUPPLY; INTERNAL, AC-DC; 90-264VAC 47-63HZ,
103-127V
AC 360-440HZ IN; +12V 44A, +12VSB 1.25A OUT; I2C, PSON,
ACOK, PWRGOOD SIGNALS; SAFETY CONTROLLED, SAFETY
CONTROLLED
-5 211-1584-XX 20 SCREW, MACHINE, M3 X 0.5 X 6MM PAN HEAD, TORX T10
-6 174-6612-XX 1 CABLE, POWER, PWR SUP TO CARRIER, SAFETY CONTROLLED
-7 174-6613-XX 1 CABLE, PS TO CARRIER, SIGNALS (2X6 DISCRETE, .100 CTRS,
LATCHING), SAFETY CONTROLLED
-8 174-6614-XX 1 CABLE ASSEMBLY (LINE INPUT), SAFETY CONTROLLED
-9 348-2082-XX 4 GROMMET, FAN MOUNT, NOISE DAMPING
-10 119-8397-XX 1 FAN WITH 2X2 CONN, 60X25MM, 12V, SAFETY CONTROLLED
-11 343-0549-XX 1 STRAP, TIEDOWN; 0.098 W X 4.0 L, ZYTEL
Replaceable parts
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Service Manual 43
