Tektronix 5 Series

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-3 441-2825-XX Below B020000
Below C040000
1 ASSEMBLY, CHASSIS, MID-PLANE, SAFETY CONTROLLED
Return the instrument to T
ektronix for service.
441-2942-XX B020000 and above
C040000 and above
1 ASSEMBLY, CHASSIS, MID-PLANE
Return the instrument to Tektronix for service.
-4 407-6020-XX 1 BRACKET, GUIDE, BAFFLE
Return the instrument to Tektronix for service.
-5 211-1584-XX 20 SCREW, MACHINE, M3 X 0.5 X 6MM PAN HEAD, TORX T10
-6 870-1115-XX 1 CIRCUIT BD ASSY; MAIN; MDO 4CH; 389482600; TESTED
Return the instrument to Tektronix for service.
870-1087-XX 1 CIRCUIT BD ASSY; MAIN ;MDO 8CH; 389482600; TESTED
Return the instrument to Tektronix for service.
-7 167-2568-XX - IC, MEMORY, DRAM; DDR3, 2GB 256MX72, DDR3-1866, ECC,
SODIMM 204
Return the instrument to Tektronix for service.
2 4 channel quantity
4 6 and 8 channel quantity
-8 407-5956-XX - BRACKET, SO-DIMM RETENTION, ASSEMBLY
Return the instrument to Tektronix for service.
2 4 channel quantity
4 6 and 8 channel quantity
Replaceable parts
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Service Manual 45
