Tektronix 5 Series

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-3 211-1584-XX - SCREW, MACHINE, M3 X 0.5 X 6MM PAN HEAD, TORX T10
34 4 channel quantity
40 6 channel quantity
46 8 channel quantity
-4 174-6610-XX 1 CABLE ASSY, DISPLAY-FRONT PANEL
Return the instrument to T
ektronix for service.
-5 174-6698-XX Below B020000
Below C040000
1 CABLE, TOUCH SCREEN TO FRONT PANEL
Return the instrument to Tektronix for service.
174-7244-XX B020000 and above
C040000 and above
1 CABLE, DISCRETE WIRE TOUCH CONTROLLER TO FRONT PANEL
Return the instrument to Tektronix for service.
-6 366-0920-XX 1 BUTTON, POWER SWITCH, SAFETY CONTROLLED
Return the instrument to Tektronix for service.
-7 878-1042-XX Below B020000
Below C040000
1 CIRCUIT BD ASSY; PROBE INTERFACE; 389483000;UNTESTED
Return the instrument to Tektronix for service.
878-1717-XX B020000 and above
C040000 and above
1 CIRCUIT BOARD ASSY;PROBE INTERFACE, 3895488XX
Return the instrument to Tektronix for service.
-8 174-7380-XX - CABLE, FLAT FLEX, SHIELD W/GND 0.5MM PITCH
Return the instrument to Tektronix for service.
2 4 channel quantity
3 6 channel quantity
4 8 channel quantity
-9 211-1585-XX - SCREW, 3 X 0.5 X 8.0 THREAD FORMING PAN HEAD, TORX T10
43 4 channel quantity
51 6 channel quantity
59 8 channel quantity
-10 174-6879-XX 1 CABLE, PICO-LOCK, 10 PIN
Return the instrument to Tektronix for service.
-11 441-2827-XX Below B020000
Below C040000
1 CHASSIS, FRONT, SAFETY CONTROLLED
Return the instrument to Tektronix for service.
441-2941-XX B020000 and above
C040000 and above
1 CHASSIS, FRONT
Return the instrument to Tektronix for service.
-12 348-2297-XX B020000 and above
C040000 and above
1 GASKET, CONDUCTIVE, FOF W/PSA 1MM X 7MM X 290MM
Table continued…
Replaceable parts
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Service Manual 47
