Tektronix AFG3000 Series Technical Reference

Specifications
These specifications apply to all AFG3000 Series Arbitrary Function Generators.
All specifications are guaranteed unless labeled “typical”. Typical specifications
are p rovided
for your convenience but are not guaranteed.
Specifications that are check marked with the
symbol are checked directly (or
indirectly
) in the Performance Verification section.
All specifications apply to the arbitrary function generator unless noted otherwise.
These spec
ifications are valid under the following conditions:
The instrument must have been calibrated/adjusted at an ambient tempera ture
between +
20 °C and +30 °C.
The instrument must be operating at an ambient temperature between 0 °C
and +50 °
C.
The instrument must have had a warm-up period of at least 20 minutes.
The instrument must be in an environment with temperature, altitude, and
humidity within the operating limits described in these specifications.
Electrical specifications
Ta ble 2: Operating mode
Characteristic Description
Run m ode
Continuous, Modulation, Sweep, and Burst
Burst count
1 to 1,000,000 cycles or infinite
Internal trigger rate 1.000 μs to 500.0 s
AFG3000 Series Specifications and Performance Verification 5
