Tektronix AFG3000 Series Technical Reference

Specifications
Ta ble 13: Rear panel (cont.)
Characteristic Description
Frequency range
AM, FM, PM, FSK, PWM: DC to 25 kHz (sampling rate: 122 kS/s)
External reference output AFG3011 / 3011C / 3101 / 3101C / 3102 / 3102C / 3251/ 3251C / 3252 / 3252C
Impedance
50 Ω, AC coupled
Amplitude, typical
1.2 Vp-p into 50 Ω
External reference input
Impedance
1kΩ, AC c oupled
Required input voltage swing 100 mVp-p to 5 Vp-p
Lock range 10 MHz ± 35 kHz
CH1 Additional input AFG3101 / 3101C / 3102 / 3102C / 3251 / 3251C / 3252 / 3252C
Impedance
50 Ω
Input range
-1 V to +1 V (DC + peak AC)
Bandwidth
DC to 10 MHz (-3 dB) at 1 Vp-p
General specifications
Table 14: Power
Characteristic Description
Source voltage and frequency
100 V to 240 V, 47 Hz to 63 Hz
115 V, 360 to 440 Hz
Power consumption Less than 120 W
T
able 15: Environmental
Characteristic Description
Temperature range
Operating 0 °C to +50 °C
Non operating
-30°Cto+70°C
Humidity
Operating
(non condensing)
0°Cto+40°C:≤ 80%
+40°Cto+50°C:≤ 60%
Non operating
(non condensing)
<+40 °C: 5% to 90%
≥+40 °C to ≤+60 °C: 5% to 80%
>+60 °C to ≤+70 °C: 5% to 40%
Altitude
Operating Up to 3,000 meters (9,843 feet)
Non operating
Up to 12,000 meters (39,370 feet)
AFG3000 Series Specifications and Performance Verification 17
