Tektronix AFG3000 Series Technical Reference

Performance verification
AFG310x / 310xC Measurement Range
Function Amplitude Frequency
(dB) (dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 50.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 100.00 MH
z
Reference ± 0.50
AFG325x / 325xC Measurement Range
Function Amplitud
e
Frequenc
y
(dB) (dB)
Sine
+ 4.0 dBm 1.00 kHz
= R eference
------
Sine
+4.0dB
m
1.00 MH
z
Reference ± 0.15
Sine
+4.0dB
m
5.00 MH
z
Reference ± 0.30
Sine
+4.0d
Bm
25.00
MHz
Reference ± 0.50
Sine
+4.0d
Bm
50.00
MHz
Reference ± 0.50
Sine
+4.0
dBm
100.
00 MHz
Reference ± 1.00
Sine
+4.
0dBm
150
.00 MHz
Reference ± 1.00
Sine
+4.
0dBm
240
.00 MHz
Reference ± 2.00
Ha
rmonics Distortion test
This test verifies the harmonic distortion using a spectrum analyzer.
1. Connect the arbitrary function generator to the spectrum analyzer as shown in
the following figure.
Figure 9: Harmonic distortion tests
2. Push the D efault front-panel button a nd OK me nu button to recall the arbitrary
function generator default setup.
56 AFG3000 Series Specifications and Performance Verification
