Tektronix AFG3000 Series Technical Reference

Performance verification
3. Set up the arbit
rary function generator using the following steps:
Select menu Setting Operation
Function
Sine Sine (front)
Frequency
20.00 kHz: AFG3011 /
3011C / 302x
B / 302xC /
305xC
1.000 MHz: AFG310x /
310xC / 325x
/ 325xC
Frequency/Period (front)
Amplitude Units Vpp
TopMenu > A
mplitude/Level Menu >
-more- > Units > Vpp
Amplitude 1.00 Vpp
Amplitude/High (front)
Channel 1 Output On On (front)
4. Set up the spectrum analyzer according the frequency setup of the arbitrary
function generator.
5. Set the Ref Level of the spectrum analyzer to 8 dBm.
6. Read the signal level in the Fundamental frequency for each signal. Use this
level as a Reference value in step .
7. Verify that the differences between the reference level and the signal level in
the frequency of higher-order at each frequency are below the limit specified
in the following tables.
8. (Two channel models only) Repeat steps 2 through 4 for the channel 2 output.
AFG3011 /
3011C Spectrum Analyzer Measurement Limit
Frequency
Center
Frequency
Span
RBW Fundamental
(=
Reference)
2nd 3rd 4th 5th Nth -
Reference
20.00 kHz 100 kHz 200 kHz 500 Hz 20 kHz 40 kHz 60 kHz 80 kHz 100 kHz < -55 dBc
100.00 kHz 500 kHz 1 MHz 2 kHz 100 kHz 200 kHz 300 kHz 400 kHz 500 kHz < -55 dBc
1.00 MHz 5.00 MHz 10 MHz 20 kHz 1 MHz 2 MHz 3 MHz 4 MHz 5 MHz < -45 dBc
10.00 MHz
10 MHz/
50 MHz
20 MHz/
100 MHz
20 kHz/
20 kHz
10 MHz 20 MHz 30 MHz 40 MHz 50 MHz < -45dBc
AFG302xB
/ 302xC Spectrum Analyzer Measurement Limit
Frequency
Center
Frequency
Span
RBW Fundamental
(=
Reference)
2nd 3rd 4th 5th Nth -
Reference
20.00 kHz 100 kHz 200 kHz 500 Hz 20 kHz 40 kHz 60 kHz 80 kHz 100 kHz < -60 dBc
100.00 kHz 500 kHz 1 MHz 2 kHz 100 kHz 200 kHz 300 kHz 400 kHz 500 kHz < -60 dBc
AFG3000 Series Specifications and Performance Verification 57
