Tektronix AFG3000 Series Technical Reference

Performance verification
Table 20: AFG30
00 Series Performance Test Record
Instrument Serial Number: Certificate Number:
Temperature:
RH %:
Date of Calibration:
Technician:
Frequency, Amplitude, DC Offset, and AC Flatness Test Record
Minimum Test result Maximum
Frequency
Sine at 1.000000 MHz
0.999999 MHz 1.000001 MHz
Pulse at 1.000000 MHz 0.999999 MHz 1.000001 MHz
Amplitude (AFG3011 / 3011C)
CF = 2 / (1
+50Ω / Measurement Ω)=
CH1 Ampl
itude
Minimum Test result Maximum
30.0 mVrms at 1.00 kHz
(30.0 ×
CF - 1.307) mVrms
(30.0 ×
CF + 1.307) mVrms
300.0 mVrms at 1.00 kHz
(300.0
× CF - 6.71) mVrms
(300.0
× CF + 6.71) mVrms
800.0 mVrms at 1.00 kHz
(800.
0 × CF - 16.71) mVrms
(800.
0 × CF + 16.71) m Vrms
1.500 Vrms at 1.00 kHz
(1.5
00 × C F - 0.0307) Vrms
(1.5
00 × C F + 0.0307) Vrms
2.000 Vrms at 1.00 kHz
(2.0
00 × C F - 0.0407) Vrms
(2.0
00 × C F + 0.0407) Vrms
2.500 Vrms at 1.00 kHz
(2.
500 × C F - 0.0507) Vrms
(2.
500 × C F + 0.0507) Vrms
3.500 Vrms at 1.00 kHz
(3.
500 × C F - 0.0707 Vrms
(3.
500 × C F + 0.0707) Vrms
Am
plitude (AFG302xB / 302xC / 305xC / 310x / 310xC)
CF = 2 / (1 + 50 Ω / Measurement Ω)=
CH1 Amplitude
Minimum Test result Maximum
30.0 mVrms at 1.00 kHz
(30.0 × CF - 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz
(300.0 × CF - 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz
(800.0 × CF - 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz
(1.500 × C F - 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
2.000 Vrms at 1.00 kHz
(2.000 × C F - 0.0204) Vrms (2.000 × CF + 0.0204) Vrms
2.500 Vrms at 1.00 kHz
(2.500 × C F - 0.0254) Vrms (2.500 × CF + 0.0254) Vrms
3.500 Vrms at 1.00 kHz
(3.500 × C F - 0.0354) Vrms (3.500 × CF + 0.0354) Vrms
CH2 Amplitude
Minimum Test result Maximum
30.0 mVrms at 1.00 kHz
(30.0 × CF - 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz
(300.0 × CF - 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz
(800.0 × CF - 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz
(1.500 × C F - 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
2.000 Vrms at 1.00 kHz
(2.000 × C F - 0.0204) Vrms (2.000 × CF + 0.0204) Vrms
2.500 Vrms at 1.00 kHz
(2.500 × C F - 0.0254) Vrms (2.500 × CF + 0.0254) Vrms
28 AFG3000 Series Specifications and Performance Verification
