Tektronix AFG3000 Series Technical Reference

Specifications
Table 3: Wavefo
rms
Characteristic Description
Standard Sine, Square, Pulse, Ramp, More (Sin(x)/x, Noise, DC, Gaussian, Lorentz, Exponential Rise,
Exponential Decay, and Haversine)
Arbitrary waveform
Waveform length
2 to 131,072
Sampling rate
AFG3021B / 3022B /
3021C / 302
2C / 3011/
3011C
250 MS/s
AFG3101 / 3101C / 3102
/ 3102C / 3051C / 3052C
250 MS/s or 1 GS/s (rate changes automatically at ≤16K)
AFG3251 / 3251C / 3252
/ 3252C
250 MS/s or 2 GS/s (rate changes automatically at ≤16K)
Resolution 14 bits
Number of non-volatile
wavefo
rm memories
4
Table 4: (Category) specifications
Characteristic Description
PV reference
page
Frequency range
Sine
1
AFG3011 / 3011C
1 μHz to 10 MHz
AFG3021B / 3021C /
3022B / 3022C
1 μHz to 25 MHz
AFG3051C / 3052C
1 μHz to 50 MHz
AFG3101 / 3101C / 3102
/ 3102C
1 μHz to 100 MHz
AFG3251 / 3251C / 3252
/ 3252C
1 μHz to 240 MHz
Square
AFG3011 / 3011C
1 μHz to 5 MHz
AFG3021B / 3022B
1 μHz to 12.5 MHz
AFG3021C / 3022C
1 μHz to 25 MHz
AFG3051C / 3052C
1 μHz to 40 MHz
AFG3101 / 3101C / 3102
/ 3102C
1 μHz to 50 MHz
AFG3251 / 3251C / 3252
/ 3252C
1 μHz to 120 MHz
Pulse
AFG3011 / 3011C
1 mHz to 5 MHz
6 AFG3000 Series Specifications and Performance Verifi cation

Tektronix AFG3000 Series Specifications
