Tektronix AFG3000 Series Technical Reference

Performance verification
2. Set up the arbit
rary function generator using the following steps:
Select menu Setting Operation
Function
Sine Sine (front)
Frequency 500 kHz
Frequency/Period (front)
Amplitude Units dBm
TopMenu > Amplitude/Level Menu >
-more- > Units > dB m
Amplitude + 4.0 dBm
Amplitude/High (front)
Channel 1 Output On On (front)
3. Set the frequency of the Power Meter to 500 kHz.
4. Verify that the power measurement at each frequency is within the error
specified in the following tables.
5. (Two channel models only) Repeat steps 3 through 4 for the channel 2 output.
AFG3011 / 3011C Measurement Range
Function Amplitude Frequency
(dB) (dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dB m 500 kHz
Reference ± 0.15
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 10.00 MHz
Reference ± 0.30
AFG302xB / 302xC Measurement Range
Function Amplitude Frequency
(dB) (dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm 5.00 kHz
Reference ± 0.15
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 15.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.50
AFG305xC Measurement Range
Function Amplitude Frequency
(dB) (dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm 5.00 kHz
Reference ± 0.15
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 15.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 50.00 MHz
Reference ± 0.50
AFG3000 Series Specifications and Performance Verification 55
