Tektronix AFG3000 Series Technical Reference

Performance verification
Frequency, Amplitude, DC Offset, and AC Flatness Test Record (cont.)
Amplitude (AFG325x / 325xC)
CF = 2 / (1 + 50 Ω / Measurement Ω)=
CH1 Amplitude
Minimum Test result Maximum
0.030 Vrms at 1.00 kHz
(30.0 × CF - 0.654) mVrms (30.0 × CF + 0.654) mVrms
0.300 Vrms at 1.00 kHz
(300.0 × CF - 3.35) mVrms (300.0× CF + 3.35) mVrms
0.800 Vrms at 1.00 kHz
(800.0 × CF - 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz
(1.500 × C F - 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
CH2 Amplitude
Minimum Test result Maximum
30.0 mVrms at 1.00 kHz
(30.0 × CF - 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz
(300.0 × CF - 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz
(800.0 × CF - 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz
(1.500 × C F - 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
DC Offset (AFG3011 / 3011C)
CF = 2 / (1 + 50 Ω / Measurement Ω)=
CH1 DC Offset
Minimum Test result Maximum
+5.000 Vdc
(+5.000 × CF - 0.110) Vdc (+5.000 × CF + 0.110 Vdc
0.000 Vdc -0.010 Vdc +0.010 Vdc
-5.000 Vdc
(-5.000 × CF - 0.110) Vdc (-5.000 × CF + 0.110) Vdc
DC Offset (AFG302xB / 302xC / 305xC / 310x / 310xC)
CF = 2 / (1 + 50 Ω / Measurement Ω)=
CH1 DC Offset
Minimum Test result Maximum
+5.000 Vdc
(+5.000 × C F - 0.055) Vdc (+5.000 × CF + 0.055 V dc
0.000 Vdc -0.005 Vdc +0.005 Vdc
-5.000 Vdc
(-5.000 × CF - 0.055) Vdc (-5.000 × CF + 0.055) Vdc
CH2 DC Offset
Minimum Test result Maximum
+5.000 Vdc
(+5.000 × C F - 0.055) Vdc (+5.000 × CF + 0.055) Vdc
0.000 Vdc -0.005 Vdc +0.005 Vdc
-5.000 Vdc
(-5.000 × CF - 0.055) Vdc (-5.000 × CF + 0.055) Vdc
DC Offset (AFG325x / 325xC)
CF = 2 / (1 + 50 Ω / Measurement Ω)=
CH1 DC Offset
Minimum Test result Maximum
+2.500 Vdc
(+2.500 × C F - 0.030) Vdc (+2.500 × CF + 0.030 V dc
0.000 Vdc -0.005 Vdc +0.005 Vdc
-2.500 Vdc
(-2.500 × CF - 0.030) Vdc (-2.500 × CF + 0.030) Vdc
CH2 DC Offset
Minimum Test result Maximum
30 AFG3000 Series Specifications and Performance Verification
