Performance veriﬁcation

Frequency, Amplitude, DC Offset, and AC Flatness Test Record (cont.)

AC Flatness (AFG3011 / 3011C)

CH1 AC Flatness

Minimum Test result Maximum

Frequency 1.00 kHz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 500 kHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 10.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

AC Flatness (AFG302xB / 302xC)

CH1 AC Flatness

Minimum Test result Maximum

Frequency 1.00 kHz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 500 kHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 15.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

CH2 AC Flatness

Frequency 1.00 kHz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 500 kHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 15.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

AC Flatness (AFG305xC)

CH1 AC Flatness

Minimum Test result Maximum

Frequency 1.00 kHz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 500 kHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 10.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 15.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 50.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

32 AFG3000 Series Speciﬁcations and Performance Veriﬁcation
