Tektronix AFG3000 Series Technical Reference

Performance verification
Rise/Fall Time Test Record (cont.)
Fall Time Amplitude: 10.0 Vpp
-----
50 ns
AFG302xB
CH1
Rise Time Amplitude: 1.0 Vpp
-----
9ns
Fall Time Amplitude: 1.0 Vpp
-----
9ns
Rise Time Amplitude: 10.0 Vpp
-----
9ns
Fall Time Amplitude: 10.0 Vpp
-----
9ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
9ns
Fall Time Amplitude: 1.0 Vpp
-----
9ns
Rise Time Amplitude: 10.0 Vpp
-----
9ns
Fall Time Amplitude: 10.0 Vpp
-----
9ns
AFG302xC
CH1
Rise Time Amplitude: 1.0 Vpp
-----
18 ns
Fall Time Amplitude: 1.0 Vpp
-----
18 ns
Rise Time Amplitude: 10.0 Vpp
-----
18 ns
Fall Time Amplitude: 10.0 Vpp
-----
18 ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
18 ns
Fall Time Amplitude: 1.0 Vpp
-----
18 ns
Rise Time Amplitude: 10.0 Vpp
-----
18 ns
Fall Time Amplitude: 10.0 Vpp
-----
18 ns
AFG305xC
CH1
Rise Time Amplitude: 1.0 Vpp
-----
7ns
Fall Time Amplitude: 1.0 Vpp
-----
7ns
Rise Time Amplitude: 10.0 Vpp
-----
7ns
Fall Time Amplitude: 10.0 Vpp
-----
7ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
7ns
Fall Time Amplitude: 1.0 Vpp
-----
7ns
Rise Time Amplitude: 10.0 Vpp
-----
7ns
Fall Time Amplitude: 10.0 Vpp
-----
7ns
AFG310x / 310xC
CH1
Rise Time Amplitude: 1.0 Vpp
-----
5ns
Fall Time Amplitude: 1.0 Vpp
-----
5ns
AFG3000 Series Specifications and Performance Verification 47
