Performance verification
4. Set up the arbit
rary function generator using the following steps:
Select menu Setting Operation
Function
Sine Sine (front)
Frequency 1.000000 kHz
Frequency/Period (front)
Amplitude Units V rms The voltage unit should
be matched to that of DMM.
Top Menu > Amplitude/Level Menu >
-mor
e- > Units > V rms
Amplitude 0.030 Vrms
Amp
litude/High (front)
Ch
annel 1
Output
On On
(front)
5. Verify that each amplitude measurement is within the range specified in the
following tables.
6. (Two channel models only) Repeat steps 3 through 4 for the channel 2 output.
AFG3011 / 3011C
Function Frequency A mplitude Measurement Range
Sine
1.000 kHz 30.0 m Vrms mVrms
(30.0 × CF ± 1.307) mVrms
Sine
1.000 kHz 300.0 m Vrms mVrms
(300.0 × CF ± 6.71) mVrms
Sine
1.000 kHz 800.0 m Vrms mVrms
(800.0 × CF ± 16.71) mVrms
Sine
1.000 kHz 1.500 Vrms Vrms
(1.500 × CF ± 0.0307) Vrms
Sine
1.000 kHz 2.000 Vrms Vrms
(2.000 × CF ± 0.0407) Vrms
Sine
1.000 kHz 2.500 Vrms Vrms
(2.500 × CF ± 0.0507) Vrms
Sine
1.000 kHz 3.500 Vrms Vrms
(3.500 × CF ± 0.0707) Vrms
AFG302xB / 302xC / 305xC / 310x / 310xC
Function Frequency Amplitude Measurement Range
Sine
1.000 kHz 30.0 mVrms mVrms
(30.0 × CF ± 0.654) mVrms
Sine
1.000 kHz 300.0 mVrms mVrms
(300.0 × CF ± 3.35) mVrms
Sine
1.000 kHz 800.0 mVrms mVrms
(800.0 × CF ± 8.35) mVrms
Sine
1.000 kHz 1.500 Vrms Vrms
(1.500 × CF ± 0.0154) Vrms
Sine
1.000 kHz 2.000 Vrms Vrms
(2.000 × CF ± 0.0204) Vrms
Sine
1.000 kHz 2.500 Vrms Vrms
(2.500 × CF ± 0.0254) Vrms
Sine
1.000 kHz 3.500 Vrms Vrms
(3.500 × CF ± 0.0354) Vrms
AFG325x / 325xC
Function Frequency Amplitude Measurement Range
Sine
1.000 kHz 30.0 mVrms mVrms
(30.0 × CF ± 0.654) mVrms
Sine
1.000 kHz 300.0 mVrms mVrms
(300.0 × CF ± 3.35) mVrms
Sine
1.000 kHz 800.0 mVrms mVrms
(800.0 × CF ± 8.35) mVrms
Sine
1.000 kHz 1.500 Vrms Vrms
(1.500 × CF ± 0.0154) Vrms
AFG3000 Series Specifications and Performance Verification 51
