Tektronix AFG3000 Series Technical Reference

Performance verification
AFG3011 / 3011C Oscilloscope Measurement
Function Frequency
Offset
Amplitude Vertical Horizontal L imit
Square
2.00 MHz 0.0 V 1.0 Vpp
200 mV/div 20 ns/div or
25 ns/div
≤ 50 ns
Square
2.00 MHz 0.0 V 10.0 Vpp
200 mV/div
with x10
attenuator
20 ns/div or
25 ns/div
≤ 50 ns
AFG302xB / 302xC Oscilloscope Measurement
Function Frequency
Offset
Amplitude Vertical Horizontal L imit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/div 5 ns/div
≤ 9ns
Square
10.00 MHz 0.0 V 10.0 Vpp
200 mV/div
with x10
attenuat
or
5ns/div
≤ 9ns
AFG305x
C
Oscillo
scope
Measure
ment
Function Frequency
Offset
Amplitude Vertical Horizontal L imit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/
div
5ns/di
v
≤ 7ns
Square
10.00 MHz 0.0 V 10.0 Vpp
200 mV/
div
with x10
attenuator
5ns/di
v
≤ 7ns
AFG310x / 310xC Oscilloscope Measurement
Function Frequency
Offset
Amplitude Vertical Horizontal L imit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/div 2 ns/div
≤ 5ns
Square
10.00 MHz 0.0 V 10.0 Vpp
200 mV/div
wit
hx10
attenuator
2ns/div
≤ 5ns
AFG325x / 325xC Oscilloscope Measurement
Fun
ction
Fre
quency
Offset
Amp
litude
Ver
tical
Hor
izontal
Lim
it
Square
10
.00 MHz
0.
0V
1.
0 Vpp
200 mV/div 1 ns/div
≤ 2
.5 ns
Square
10
.00 MHz
0.
0V
5.
0 Vpp
1.0V/div 1ns/div
≤ 2
.5 ns
AFG3000 Series Specifications and Performance Verification 65
