Tektronix AFG3011 User Manual

Getting started
General featu
res
Each AFG3000 Series Arbitrary Function Generators offers the functionality of
three generators in one:
10 MHz to 240 MHz Function Generator
5 MHz to 120 MHz Pulse Generator
14 bits Arbitrary Waveform Generator
The following tables describe some of the general features of your instrument. An
“X” means the feature is included with the model.
Table 1: General features for regular and B models
Feature AFG3011
AFG3021B/
AFG3022B AFG3101/ AFG3102 AFG3251/ AFG3252
Channel
1
1/2 1/2 1/2
Sine
10 MHz 25 MHz 100 MHz 240 MHz
Pulse 5 MHz 12.5 MHz 50 MHz 120 MHz
Memory 2 to 131,072 2 to 131,072 2 to 16,384 >16,384 to
131,072
2 to 16,384 >16,384 to
131,072
Sampling Rate 250 MS/s 250 MS/s 1 GS/s 250 MS/s 2 GS/s 250 MS/s
Amplitude 20 Vp-p 10 Vp-p 10 Vp-p 5 Vp-p
Display
Color Monochrome/
Color
Color Color
Interface USB, LAN,
GPIB
USB, LAN,
GPIB
USB, LAN, GPIB USB, LAN, GPIB
Ground
isolation
XXX X
Synchronous
operation
XXX X
Context-sensitive
Help system
XXX X
ArbExpress®
Software
XXX X
AFG3000 and AFG3000C Series User Manual 1

Tektronix AFG3011 Specifications

General
