Getting started

3. Push the I/O Interface >

GPIB bezel buttons.

4. Push the Add

ress bezel

button to assign a unique

address to the instrument.

The GPIB ad

dress

deﬁnes a unique address

for the instrument. Each

device con

nected to the

GPIB bus must have a

unique GPIB address.

The GPIB a

ddress must

be from 0 to 30.

5. Push the Conﬁguration

bezel but

ton to toggle

the instrument bus

communications on

and off.

Talk/Li

sten - Select

this mode to remotely

control the instrument

from an

external host

computer.

Off Bus - Select this

mode to disconnect

the in

strument from

the GPIB bus.

AFG3000 and AFG3000C Series User Manual 21
