Specifications
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 23
Characteristic
Description
PV reference
page
AFG31151, AFG31152
10 Hz to <1 MHz: <–60 dBc
≥1 MHz to <25 MHz: <–47 dBc
≥25 MHz to ≤150 MHz: <–47 dBc
+ 6 dBc per octave
AFG31251, AFG31252
10 Hz to <1 MHz: <–60 dBc
≥1 MHz to <25 MHz: <–47 dBc
≥25 MHz to ≤250 MHz: <–47 dBc
+ 6 dBc per octave
Phase noise
(at 1.0 V
pp
amplitude)
20 MHz: <–110 dBc per Hz at 10 kHz offset
Residual clock
noise (typical)
AFG31021, AFG31022,
AFG31051, AFG31052,
AFG31101, AFG31102
–63 dBm
AFG31151, AFG31152,
AFG31251, AFG31252
–63 dBm
Table 13: Square wave output specifications
Characteristic Description
Square wave

Rise time/fall
time
AFG31021, AFG31022
Amplitude >5 V
pp
: 8.0 ns
Amplitude ≤5 V
pp
: 7.0 ns
AFG31051, AFG31052
Amplitude >5 V
pp
: 6.0 ns
Amplitude ≤5 V
pp
: 5.0 ns
AFG31101, AFG31102
Amplitude >5 V
pp
: 4.2 ns
Amplitude ≤5 V
pp
: 3.5 ns
AFG31151, AFG31152,
AFG31251, AFG31252
Amplitude >5 V
pp
: 3.0 ns
Amplitude ≤5 V
pp
: 2.0 ns
Overshoot
<5%
Jitter (RMS),
typical
2.5 ps RMS
Table 14: Pulse output specifications
Characteristic
Description
Pulse
Pulse width
(resolution: 10 ps
or 5 digits)
AFG31021, AFG31022 16 ns to 999.99 s
AFG31051, AFG31052
10 ns to 999.99 s
AFG31101, AFG31102
6 ns to 999.99 s
AFG31151, AFG31152
5 ns to 999.99 s
AFG31251, AFG31252
4 ns to 999.99 s
Pulse duty 0.001% to 99.999%
Leading/trailing
edge transition
time (at 10% to
90% of amplitude,
respectively);
resolution 10 ps
or 4 digits
AFG31021, AFG31022 8 ns to 0.625 × pulse period
AFG31051, AFG31052
6 ns to 0.625 × pulse period
AFG31101, AFG31102
4 ns to 0.625 × pulse period
AFG31151, AFG31152
3 ns to 0.625 × pulse period
AFG31251, AFG31252
2 ns to 0.625 × pulse period
