Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Specifications
24 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
Characteristic
Description
Overshoot, typical
<5%
Jitter (RMS),
typical
2.5 ps RMS
Table 15: Ramp output specifications
Characteristic
Description
Ramp
Linearity
(at 1 kHz
frequency,
amplitude 1 V
pp
,
symmetry 100%)
AFG31021, AFG31022,
AFG31051, AFG31052
≤ 0.1% of peak output at 10% to
90% of amplitude range
AFG31101, AFG31102
≤ 0.15% of peak output at 10% to
90% of amplitude range
AFG31151, AFG31152,
AFG31251, AFG31252
≤ 0.2% of peak output at 10% to
90% of amplitude range
Symmetry
0% to 100%
Table 16: Arbitrary output specifications
Characteristic
Description
Arbitrary
Rise/fall time, typical
AFG31021, AFG31022,
AFG31051, AFG31052,
AFG31101, AFG31102
Amplitude ≥ 5 V
pp
: 4.2 ns
Amplitude < 5 V
pp
: 3.5 ns
AFG31151, AFG31152,
AFG31251, AFG31252
≤ 2 ns
Jitter (RMS) AFG31021, AFG31022 3.0 ps RMS
AFG31051, AFG31052
2.5 ps RMS
AFG31101, AFG31102
2.0 ps RMS
AFG31151, AFG31152,
AFG31251, AFG31252
1.6 ps RMS
Table 17: DC output specifications
Characteristic Description
PV reference page
DC
Range
(resolution 1 mV or
4 digits)
AFG31021, AFG31022,
AFG31051, AFG31052,
AFG31101, AFG31102
–5 V to 5 V into 50 Ω
–10 V to 10 V into open-circuit
load
AFG31151, AFG31152,
AFG31251, AFG31252
–2.5 V to 2.5 V into 50 Ω
–5 V to 5 V into open-circuit
load
Accuracy
10
(50 Ω load)
±(1% of |DC setting| + 1 mV DC) DC test
10
Add 0.5 mV per °C for operation outside of 20 °C to 30 °C.
