Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Specifications
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 25
Table 18: Amplitude modulation (AM) specifications
Characteristic Description
Amplitude modulation (AM)
Carrier waveforms Standard waveforms (except pulse, DC, and noise) and arbitrary waveforms
Modulation source Internal or external (from modulation input)
Internal modulating
waveforms
Sine, square, ramp, noise, arbitrary
11
Internal modulating
frequency
1 mHz to 1 MHz
Depth 0% to 120%
Table 19: Frequency modulation (FM) specifications
Characteristic Description
Frequency modulation (FM)
Carrier waveforms
Standard waveforms (except pulse, DC, and noise) and arbitrary waveforms
Modulation source
Internal or external (from modulation input)
Internal modulating
waveforms
Sine, square, ramp, noise, arbitrary
12
Maximum effective points: 2048
Internal modulating
frequency
1 mHz to 1 MHz
Peak deviation
AFG31021, AFG31022
DC to 12.5 MHz
AFG31051, AFG31052 DC to 25 MHz
AFG31101, AFG31102 DC to 50 MHz
AFG31151, AFG31152
DC to 75 MHz
AFG31251, AFG31252
DC to 125 MHz
Table 20: Phase modulation (PM) specifications
Characteristic Description
Phase modulation (PM)
Carrier waveforms
Standard waveforms (except pulse, DC, and noise) and arbitrary waveforms
Modulation source
Internal or external (from modulation input)
Internal modulating
waveforms
Sine, square, ramp, noise, arbitrary
13
Maximum effective points: 2048
Internal modulating
frequency
1 mHz to 1 MHz
Phase deviation
range
0 to 180 degrees
11
For amplitude modulation, the maximum effective points for arbitrary waveforms is 128,000. Waveform data
above 128,000 points is ignored.
12
For FM, PM, and PWM modulation types, the maximum effective points for arbitrary waveforms is 2048.
Waveform data above 2048 points is ignored.
13
For FM, PM, and PWM modulation types, the maximum effective points for arbitrary waveforms is 2048.
Waveform data above 2048 points is ignored.
