Performance verification
44 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
4. Set up the AFG31000 Series as shown in the following table.
Select menu Setting Operation
Function
DC
More key (front panel) > Ch1 function > DC
Offset
18
5.000 V
2.500 V (AFG31151,
AFG31152, AFG31251,
AFG31252)
Offset/Low key (front panel) > Offset (touch screen)
Ch1 (or Ch2)
Output
On
Ch1 (or Ch2) Output On key (front panel)
5. Verify that each offset measurement is within the range specified in the following tables.
6. (Two-channel models only) Repeat steps 4 through 5 for channel 2 output.
Models AFG31021, AFG31022, AFG31051, AFG31052, AFG31101, AFG31102
Function Offset Measurement Range
DC
5.000 VDC
VDC
(5.000 × CF ± 0.051) VDC
DC 0.000 VDC VDC ±0.001 VDC
DC –5.000 VDC VDC (-5.000 × CF ± 0.051) VDC
Models AFG31151
，
AFG31152
，
AFG31251
，
AFG31252
Function Offset Measurement Range
DC 2.500 VDC VDC (2.500 × CF ± 0.026) VDC
DC
0.000 VDC
VDC
± 0.001 VDC
DC
–2.500 VDC
VDC
(-2.500 × CF ± 0.026) VDC
18
Add 0.5 mV per °C for operation outside of 20 °C to 30 °C.
