Analyze
Waveform
Data
NOTE.
Math
wavefo
rms
are
not
available
for
use
with
serial
buses.
Use
the
following
procedure
for
executing
simple
(+,
–,
×)
math
operations
on
two
w
aveforms:
1.
Push
M
for
the
Math
menu.
2.
Push
Dual
Wfm
Math
.
Dual
Wfm
Math
(M)
Label
3.
On
the
side-bezel
menu,
set
the
sources
to
channel
1
,
2
,
3
,
4
,
or
to
reference
waveforms
R1
or
R2
.
Choose
the
+
,
–
,o
r
x
operato
rs.
194
DPO2000
and
MSO2000
S
eries
Oscilloscopes
User
Manual
211
213
