Tektronix DPO3034 User Manual

Acquire the Signal
11. Push Event Tab le and select On to display a
list of I
2
C, SPI, CAN, or LIN bus packets with
timestamps.
Event
Table
On |
Off
Save Event
Table
For an RS-2 32 bus, the table lists decoded
bytes, or packets.
Push Save Event Table to save the event
table data in a .csv (spreadsheet) formatted
file on the currently selected storage d evice.
Bus information example:
Busandwaveformsexample:
DPO3000 Series Oscilloscopes User Manua l 103
