Save and Recall Information
Saving with One Button Push
After you have defined the save/recall parameters with the Save/Recall Me nu button and menu, you can save files with a single
push of the Save button. For example, if you have defined the save operation to save waveform data t o a USB drive, then each
push of the Save button will save current waveform data to the defined USB drive.
1. To define the Save button behavior, push
Save/Recall Menu.
2. Push Ass ign Save to button.
Save
Screen
Save
Waveform
Save Setup
Recall
Waveform
Recall
Setup
Assign
Save|to
Setup
File Utilities
212 DPO3000 Series Oscilloscopes User Ma nual
