Analyze Waveform Data
4. Deleteamark. Pushthenext(→)or
previous (←)arrowbuttontojumptothe
mark you want to cle ar. To remove the
current, center-positioned mark, push
Set/Clear. It w orks on both manually and
automatically created marks.
To automatically set and clear (delete) search marks:
1. Push Search.
2. Select the search type desired from the
lower-bezel menu.
Search
Off
Search
Type
Edge
Source
1
Slope
Threshold
0.00V
The search menu is s imilar to the trigger menu.
3. From the side-bezel menu , turn on the search.
196 DPO3000 Series Oscilloscopes User Ma nual
