Acquisition tab in the control window that displays. Click each of the
acquisition modes and confirm that the following statements are true.
■
Sample mode displays an actively acquiring waveform on-screen. (Note
that there is a small amount of noise present on the square wave).
■
Peak Detect mode displays an actively acquiring waveform on-screen
with the noise present in Sample mode "peak detected".
■
Hi Res mode displays an actively acquiring waveform on-screen with the
noise that was present in Sample mode reduced.
■
Average mode displays an actively acquiring waveform on-screen with
the noise reduced.
■
Envelope mode displays an actively acquiring waveform on-screen with
the noise displayed.
NOTE. Default setup enables enhanced triggering. Enhanced triggering can
cause a slower acquisition rate that can be noticed in waveform database
mode. As waveform database mode acquires 100,000 samples, the display
intensity will increase, be cleared, and then the process will start over. When
enhanced triggering is turned off, and with the specified settings and input
signal, the display reaches full intensity right away.
■
Waveform Database mode displays an actively acquiring waveform on-
screen with the noise displayed.
8. Test all channels: Repeat steps 2 through 7 until all four input channels are
verified.
9. Remove the test hookup: Disconnect the equipment from the instrument.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
106 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
