Behavior
The instrument acquires data from the channel you select for each component.
What do you want to do next?
Learn more about bus setups.
Learn about bus configuration.
Learn about digital setups.
Select the serial bus channel threshold
From the Bus Setup window, select Serial from the Bus Type list and then select from the cascading list.
NOTE. The serial bus channel Threshold option is available only on instruments with one or more of the SR- options.
To use
To change the voltage threshold level of the component Input, click the Threshold entry box and use the keypad to enter a value
or use the multipurpose knobs to select a voltage level.
Behavior
The instrument can use different voltage thresholds levels for each component.
What do you want to do next?
Learn more about bus setups.
Learn about bus configuration.
Learn about digital setups.
Bus setups
140 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
