Horizontal digital control window

NOTE. The Horizontal Digital control window is only available when a parallel bus is selected on MSO models and on DPO5000B

models with option MSOE installed, and DPO70000DX instruments with option MSOU installed.

From the Horiz /Acq menu, you can view the Digital Sample Rate and Digital Resolution of logic waveforms. The values track the

sample rate and resolution of the analog system.

To use

■

Use the Sample Rate and Scale entry boxes to set the Digital Sample Rate and the Digital Resolution.

The following screen is captured on MSO70000C/DX Series instruments:

The following screen is captured on MSO/DPO5000B Series instruments:

What do you want to do next?

Learn more about the Horizontal Setup controls.

Learn about the Acquisition Setup controls.

Horizontal and acquisition setups

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 183
