MIPI CSI-2 MIPI DSI-1

The Search For Long Packet window allows you to set the Virtual Channel, Direction, Data Type Value, Word Count, Number of

Bytes, Payload Format, Offset in bytes, and Payload Value.

Analyzing waveforms

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 337
