Behavior. For information on the controls, click the buttons.
■
Trigger Type
■
Mark All Trigger Events
■
Settings
■
Source
■
Set to 50%
■
Level
■
Pulse Width Limits
■
Polarity
■
Qualification
■
Logic pattern
■
Edit Button
■
HF Filtering
■
Envelope
NOTE. The Trigger Width screen on DPO and MSO instruments is the same except for the source selection (MSO instruments
include digital channels) and Trigger if Width Qualification options. In some instruments, the source selection is a drop-down list
and the Trigger if Width Qualification option has Occurs and Logic. In other instruments the source selection includes a combo
list and a Select button. The Trigger if Width Qualification option has Occurs, Logic, and Occurs And.
The following Trigger Width screen appears on MSO70000C/DX and DPO7000C Series instruments:
The following Trigger Width screen appears on DPO70000SX Series instruments:
Trigger setups
