Input VSWR >20 GHz models,
typical
Measured with a TekConnect TCA-292D adaptor and a network analyzer.
≤1.2 VFS settings: 0 – 17 GHz: 1.4:1
17 – 20 GHz: 1.6:1
20 – 33 GHz: 2.0:1
>1.2 VFS settings: 0 – 17 GHz: 1.4:1
17 – 33 GHz: 2.0:1
Input VSWR ≥4 GHz ≤20 GHz
models
Measured with a TekConnect SMA adapter and a network analyzer
Input Frequency VSWR < 1 V/Full Scale VSWR ≥ 1 V/Full Scale
<2.5 GHz 1.25:1 1.2:1
<6 GHz 1.5:1 1.2:1
<14 GHz 2.1:1 1.5:1
<15 GHz 2.5:1 1.5:1
<20 GHz 3.2:1 1.9:1
Input VSWR <4 GHz models
Input Frequency VSWR
<3.5 GHz 3.0:1
<2.5 GHz 2.0:1
<2 GHz 1.5:1
<1 GHz 1.2:1
Number of digitized bits 8 bits
Digitizer nonlinearity, typical < 1.0 DL (digitization level), differential; < 1 DL integral, independently based
Sensitivity range
>20 GHz models, 50 Ω 62.5 mV
FS
to 6 V
FS
≥4 GHz, ≤20 GHz models,
50 Ω
100 mV
FS
to 5 V
FS
. Below 100 mV
FS
, Full Scale (FS) is software zoom.
<4 GHz models, 50 Ω 1 mV/div to 1 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
<4 GHz models, 1 MΩ 1 mV/div to 10 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
DC gain accuracy sample or
average acquisition mode ≥4 GHz
models
± 2%
DC gain accuracy sample or
average acquisition mode <4 GHz
models
± 1.0% with 0 V net offset
Add 0.5% for ranges <2 mV/div
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
4 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
