Tektronix DSA70000D Series Technical Reference

Add 1.5% x | net offset/Max offset | for ranges <5 mV/div
Add 0.5% x | net offset/Max offset | for ranges ≥ 5 mV/div
Add 0.5% for ranges ≥ 1 V/div in 1 MΩ coupling and with net offset >10 V
DC voltage measurement
accuracy >20 GHz models
Gain setting DC measurement accuracy
Average acquisition mode
( ≥16 averages)
62.5 mV
FS
– 1.2 V
FS
±[2% | reading - net offset | +
0.4% | net offset | + 0.2% | net
offset – Vterm setting | +2.5 mV
+ 0.014 FS]
1.21 V
FS
– 6 V
FS
±[2% | reading - net offset | +
0.4% | net offset | + 12.5 mV +
0.014 FS]
Delta voltage measurement
between any two averages of
≥16 waveforms acquired under
the same setup and ambient
conditions
62.5 mV
FS
– 6 V
FS
±[2% | reading – net offset | +
0.008 FS]
DC voltage measurement
accuracy ≥4 GHz ≤20 GHz models
Gain setting DC measurement accuracy
Average acquisition mode
( ≥16 averages)
100 mV
FS
to 995 mV
FS
±[2% | reading – net offset | +
0.35% | net offset | +1.5 mV +
0.014 FS]
1 V
FS
to 5 V
FS
±[2% | reading – net offset | +
0.35% | net offset | +7.5 mV +
0.014 FS]
Delta voltage measurement
between any two averages of
≥16 waveforms acquired under
the same setup and ambient
conditions
100 mV
FS
to 5 V
FS
±[2% | reading | + 0.008 FS]
DC voltage measurement
accuracy <4 GHz models
DC accuracy (in volts)
Net offset = offset - ( position × volts/division).
Average acquisition mode
( ≥16 averages)
±(DC Gain Accuracy × | reading -(net offset) | + offset accuracy + 0.1 division)
Delta voltage measurement
between any two averages of
≥16 waveforms acquired with
the same setup and ambient
conditions
±(DC Gain Accuracy × | reading | + 0.05 division)
