The MSO/DPO72004C and MSO/DPO71604C instrument bandwidths with BWE disabled are
typical.
MSO/DPO72004C
BW Settings Bandwidth Temp constraint
20 GHz BWE
20 mV, 50 mV, 100 mV, and
250 mV/div
DC to >20 GHz <30 °C
20 GHz BWE
100 mV full scale (10 mV/div)
DC to >18 GHz <30 °C
No BWE DC to >16 GHz, typical <30 °C
MSO/DPO71604C
BW Settings Bandwidth Temp constraint
BWE DC to >16 GHz <30 °C
No BWE DC to >16 GHz, typical <30 °C
MSO/DPO71254C
BW Settings Bandwidth Temp constraint
BWE DC to >12.5 GHz <30 °C
No BWE DC to >12.5 GHz <30 °C
MSO/DPO70804C
BW Settings Bandwidth Temp constraint
BWE DC to >8 GHz <45 °C
No BWE DC to >8 GHz <45 °C
MSO/DPO70604C
BW Settings Bandwidth Temp constraint
BWE DC to >6 GHz <45 °C
No BWE DC to >6 GHz <45 °C
MSO/DPO70404C
BW Settings Bandwidth Temp constraint
BWE DC to >4 GHz <45 °C
No BWE DC to >4 GHz <45 °C
Typical temperature variation
Frequency TC, (dB/°C)
DC — 11 GHz 0
12.5 GHz – 0.02
16 GHz – 0.04
18 GHz – 0.09
20 GHz – 0.09
Analog bandwidth with P7313
active probe, ≥4 GHz models
MSO/DPO72004C, MSO/DPO71604C DC >12.5 GHz, typical
MSO/DPO71254C DC >11 GHz, typical
MSO/DPO70804C DC >8 GHz, typical
MSO/DPO70604C DC >6 GHz, typical
MSO/DPO70404C DC >4 GHz, typical
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
10 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
