Analog bandwidth 50 Ω DC
coupled <4 GHz models
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
Note: The DPO7354C is guaranteed 3.5 GHz bandwidth with BWE On and can be verified with a 4-
division sine wave. Typical bandwidth when measured with an 8-division sine wave is 3 GHz.
DPO7354C
SCALE range Bandwidth
10 mV/div to 1 V/div DC to 3.5 GHz, BWE on
DC to 2.5 GHz, BWE off
5 mV/div to 9.99 mV/div DC to 2.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
DPO7254C
SCALE range Bandwidth
10 mV/div to 1 V/div DC to 2.5 GHz
5 mV/div to 9.99 mV/div DC to 2.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
DPO7104C
SCALE range Bandwidth
5 mV/div to 1 V/div DC to 1.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
DPO7054C
SCALE range Bandwidth
5 mV/div to 1 V/div DC to 500 MHz
2 mV/div to 4.99 mV/div DC to 400 MHz, typical
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
Analog bandwidth 1 MΩ DC
coupled <4 GHz models
Full bandwidth, operating ambient temperature of ≤ 30 °C (86 °F), derated by 1% for each °C
above 30 °C (86 °F)
SCALE range Bandwidth
5 mV/div to 10 V/div DC to 500 MHz, typical
2 mV/div to 4.98 mV/div DC to 350 MHz, typical
1 mV/div to 1.99 mV/div DC to 175 MHz, typical
Analog bandwidth with TAP2500
VPI probe, typical, DPO7254C
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
SCALE range Bandwidth
≥ 100 mV/div DC to 2.5 GHz
50 mV/div to 99.5 mV/div DC to 2.0 GHz
20 mV/div to 49.8 mV/div DC to 500 MHz
10 mV/div to 19.9 mV/div DC to 200 MHz
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 11
